Cat. 6A Shielded Outlet

Compact Outlet Category 6A Shielded, 80x80mm w/shutter

Premium-Line compact outlet is in dedicated design for European market.
With the high electrical performance as well as the high quality physical material used for inner construction and outside appearance, it provides both easy and reliable field installation as well as real long time application. And in finished size 80×80mm.

FEATURES:

  • Supports T568 A&B wiring and easy installation
  • Dual type IDC connector can accept 22-26 AWG solid and stranded cables
  • Uniform standard German type
  • Color: RAL9010 or RAL1013
  • Terminate using 110 or Krone tools
  • 45°inclined port structure, plug-in-easy
  • Dust-proof shutter design

Compliant with Cat.6A requirements as :

  • ANSI/TIA-568.2-D:2018
  • EN50173-1:2018
  • ISO/IEC 11801-1 Class Ea:2017

Compliant with safety standard as:

  • RoHS (EU Directive 2011/65/EC)

APPLICATION:

  • 10GBASE-T Ethernet
  • 1000BASE-TX Gigabit Ethernet
  • 1000BASE-T Gigabit Ethernet
  • 100BASE-TX Fast Ethernet.
  • 10BASE-T Ethernet
  • Voice, Video and other applications

CHARACTERISTICS:

Dielectric Strength1000V RMS for 1min
Current Rating1.5Amp Max.
Insulation Resistance10MΩ Min.
Contact Resistance2mΩ per contact
Temperature Range-10° to 60° C
Humidity10%~90%; non condensing
Material Flame RatingUL94 V-0
PlateABS
Top & Bottom CaseZinc die casting alloys
Jack45° 8P8C RJ45 jack
Phosphor bronze 50μ inch gold plated over nickel in contact area
Shielded: bronze with nickel plated
Plastic housing: engineering thermoplastic
Operating life: Minimum 750 insertions
IDCDual 8pin IDC
Main body: PC
IDC Contacts:100μ inch nickel plated over phosphor bronze
Operating life: Minimum 250 Re-terminations
Dimension (L*W*H)80.0*80.0*38.6mm

ORDERING INFORMATION:

Part NO.                       1119212×1

Description                  Cat.6A shielded compact outlet with shutter, 80x80mm

x, color                          8: RAL1013 (oyster white)        9: RAL9010 (pure white)

Packing                         1pc/ PE bag, 5pcs/PE bag, 75pcs/carton
